Summum Pro 6" 5" Adjustable Wall Support & Tee Bracket
Exterior Base Support & Intermediate Lateral Wall Stabilizer (Up to 5" Standoff) — Model SC-6AWB
Provide unyielding structural anchorage and wind stability for your exterior chimney stack with the official Summum Pro 6" 5" Adjustable Wall Support & Tee Bracket (Model #SC-6AWB). Precision-engineered in Canada, this dual-purpose mounting assembly combines a heavy-gauge 304 mirror-finish stainless steel clamping band with heavy corrosion-resistant galvanized mounting brackets. Sized to fit the 9-inch outer casing of Summum Pro 6" insulated chimney pipe, it adjusts continuously from 2 inches up to 5 inches of wall clearance—carrying the full vertical deadweight of the stack when mounted directly above the insulated tee, or stabilizing tall exterior runs against fierce roofline wind shears at required 8-foot intervals.
Summum Pro 6" 5" Adjustable Wall Support Dimensions, Bracket Standoff & Clamping Profile
- Dual Structural Utility: Serves as both the primary load-bearing foundation when installed directly above an exterior cleanout tee, and as a code-mandated lateral stabilizer along tall chimney stacks.
- Continuous Standoff Adjustment up to 5": Slotted heavy-gauge side brackets allow easy adjustment from 2" to 5" away from the exterior wall plane, easily compensating for siding laps, brick veneers, or wall strapping.
- Mandatory 8-Foot Spacing Component: Essential safety component required every 8 feet of vertical chimney stack rise (minimum 2 brackets per system) to lock pipes firmly against buffeting winds and heavy Canadian winter snow loads.
- 100% True 304 Stainless Steel Collar Band: Clamping band is fabricated from premium .019" thick 304 mirror-finish stainless steel, delivering lifetime rust resistance against coastal salt spray, moisture, and creosote wash.
- Heavy Galvanized Mounting Brackets: Thick, structural-grade galvanized steel arms anchor firmly into exterior wall studs or masonry using heavy-duty lag fasteners without flexing or vibrating.
- CAN/ULC-S629 Certified System Component: Fully tested and certified by OMNI Laboratories to withstand intense 2100°F (1150°C) chimney fire conditions with just 2" clearance to combustibles.
- Limited Lifetime Warranty: Backed by Summum Pro's generous 10-year 100% component replacement warranty and 50% replacement coverage thereafter when installed by a certified WETT or APC technician.
